Systemc Implementation of a Risc-Based Processor Architecture

Increasing the complexity of the electronic systems§leads to electronic system level modeling concept§supporting hardware and software co-design and§co-verification environment in a single framework.§SystemC, an IEEE approved electronic design§standard for system design and verification§processes, provides such an environment by supporting§a wide range of abstraction levels from system-level§to register-transfer level. In this book, two§different models of a processor core, whose§instruction set architecture is compatible with§TI MSP430 microcontroller, are designed by§employing the classical hardware modeling capability§of the SystemC. With its well-designed orthogonal§instruction set, elegant addressing modes, useful§constant generators and flexible von-Neumann§architecture, 16-bit RISC-like processor of the§MSP430 microcontroller is an ideal selection for the§SoC designs. Instruction set and addressing modes of§the designed processors are simulated thoroughly.§Moreover, original CRC programs are used to verify§the processor cores. SystemC to§hardware flow is also illustrated by synthesizing the§ALU part of the processor into a Xilinx-based §hardware.
